雙組份打膠機的操作步驟
1、接通氣源：
1, connect the gas source:
電源接通，調節減壓閥0.4~0.6Mpa，檢查系統有無漏氣現象。然后試運行以下動作：（1）A泵提升；（2）A泵充氣；（3）B泵提升；（4）B泵充氣。注意：提升氣缸提升時，如果兩氣缸不同步，請下降原點后重新操作。
The source is connected and the pressure relief valve is adjusted to 0.4~0.6Mpa to check the leakage of the system. Then try to run the following actions: (1) A pump lifting; (2) A pump inflated; (3) B pump lifting; (4) B pump inflated. Note: when lifting the cylinder, if the two cylinder is not synchronized, please drop back to the original point and re operate.
2、將A、B組份膠桶就位，并與A、B膠泵的軸線對中。
2, the A, B component glue barrel is in place, and the axis of A, B glue pump is in the center.
以A組份為例：
Take A as an example:
1)操作手動轉閥，將A泵提升高，提升過程中觀察各管路有無拉伸過緊處。
1) operate the manual transfer valve to elevate the A pump to the highest level.
2)將膠桶放置在A泵壓膠盤下，開啟膠桶，將其中塑料袋外翻桶外，膠面塑料片取出。
2) put the glue barrel under the A pump press disc, open the glue barrel, turn the plastic bag out to the bucket, and take the plastic sheet out.
3)使A泵壓盤緩慢下降，壓盤入桶時應使其與桶口對準，將壓膠盤排氣口打開，直到壓盤接觸膠面。待壓盤內氣體全部排放完并有少量膠從排氣口溢出時，即可關閉排氣閥。
3) slow down the pressure plate of the A pump, when the pressure plate enters the barrel, it should be aligned with the buckets, and the vent opening of the press disc is opened until the press disc is exposed to the rubber surface. The exhaust valve can be closed when the gas is completely discharged and a small amount of glue is spilled from the exhaust port.
4)開機試打膠：將主泵氣源開關打開，按下膠槍開關，直A泵里空氣排凈槍口處出膠連續時停止。
4) open machine test glue: open the main pump gas switch, press the glue gun switch until the air in the A pump is discharged at the mouth of the gun and stops when the glue is continuous.
用同樣的方法操作B泵。
Operate the B pump in the same way.
希望上述介紹對您有所幫助哦，我們以真誠貼近客戶，以行動滿足客戶，以雙贏保有客戶，以個性客戶，您的滿意是我們大的追求。
I hope this introduction can help you. We sincerely close to customers, take actions to satisfy customers, win customers and personalities lead customers. Your satisfaction is our greatest pursuit.
